This VU reference category is retained to help customers find the existing slewing-bearing information. Schaeffler classifies VU as a gearless four-point-contact ball slewing bearing, so VU reference data must be distinguished from cylindrical crossed roller designs. View VU series table · Request a drawing or quote
Search a model or enter any known dimensions.
Exact dimensions in mm. B/H is the overall width or height. Check mounting details on the product page.
Showing all 11 results
Four-Point Contact Ball Slewing Bearings
Four-Point Ball Slewing Bearing
200 × 290 × 24 mm
Bore d × Outside D × Width / height B/HFour-Point Ball Slewing Bearing
124.5 × 234 × 35 mm
Bore d × Outside D × Width / height B/HFour-Point Ball Slewing Bearing
270 × 380 × 35 mm
Bore d × Outside D × Width / height B/HFour-Point Ball Slewing Bearing
138 × 302 × 46 mm
Bore d × Outside D × Width / height B/HFour-Point Ball Slewing Bearing
191 × 329 × 46 mm
Bore d × Outside D × Width / height B/HFour-Point Ball Slewing Bearing
336 × 474 × 46 mm
Bore d × Outside D × Width / height B/HFour-Point Ball Slewing Bearing
275 × 485 × 55 mm
Bore d × Outside D × Width / height B/HFour-Point Ball Slewing Bearing
344 × 522 × 55 mm
Bore d × Outside D × Width / height B/HFour-Point Ball Slewing Bearing
468 × 680 × 68 mm
Bore d × Outside D × Width / height B/HFour-Point Ball Slewing Bearing
565 × 795 × 79 mm
Bore d × Outside D × Width / height B/H| Check before selection | Information to provide |
|---|---|
| 1 | Actual rolling-element structure in the LYDL drawing |
| 2 | Bore and outside diameter from the dimension row, not the model code |
| 3 | Fixing holes, clearance, load diagram and drive arrangement |
For a gearless crossed roller reference family, compare XU. The two rolling-element types must not be assumed equivalent. Compare related series.
Individual model pages are being added. Use the series table or send the complete model number and drawing for review.
The LYDL-specific VU rolling-element configuration remains subject to drawing confirmation. The existing URL and category are retained. Model fragments such as 140 or 803 are not used as bore dimensions.
Technical reference: Schaeffler slewing ring catalogue 404. Brand names identify reference families only. Supplied LYDL dimensions, tolerances, load ratings and acceptance requirements are defined by the drawing and quotation agreed for the order.
Request a drawing or quote with the complete model, quantity, loads, speed, duty cycle and mounting requirements.
